Specifications:
Super small and lightweight
Detachable camera vtx design
Power by 1S lipo battery
With dipole whip antenna
Power off memory function: restart as the very last channel kept before power off
Button control instead of switch
Easy to install, plug and play
Camera:
Model Number-V60T
Power supply 3.7-5V
Current consumption 60mA
Resolution 600TVL
FOV 120 degree
Video format NTSC
Mini illumination 1.0 lux
Dimension 14x14mm
Weight 2g
Video Transmitter:
Model number FX806T
Power supply 2.5-5V
150mA@3.7V,110mA@5V
Working frequency 5.8GHz
Output power 25mW
Channel 40 channels with Raceband
Video band width 6.0MHz
Antenna dipole whip antenna or other antenna
Dimension 19x14mm
|
